Option Parts for general-purpose

A set of 5 male 24K gold-plated 2P plugs that have become a standard for electric power.
■ We adopt 24K gold plating plating.
■ A Type (male), 5 pieces.
■ Comes with shrink tube in each color of black and red.

Option parts for the TURBO OPTIMA.
Soft compound of 50mm tire. For low grip road surface

Spare Parts for OPTIMA

[Contents]
・ Motor checker body
・ Power cable with super plug ・
O-ring for fixing motor x2 (1 is spare)
・ Rotation adapter x2 (1 is spare)
・ Wiring cable with alligator clip for brush motor
・ Instruction instructions book

[Items that need to be purchased separately] -Battery
motor or brushless motor for minutes (measurement target)
-Battery with super plug from 5.5V to 7.4V (maximum voltage up to 8.4V)
  or MZW124-02 AC adapter (6V- 2A / For Japan)

Aluminum impact resistant front and rear bumpers.

Steering plate set. 5 kinds of toe angles can be selected for wider setup range.

Aluminum knuckles. Provides increased rigidity and better appearance.

Spare part for the Inferno GT2.

Recommended Stand for working on the damper. The magnet plate on the front will help preventing to lost screws.

■Length 167.0mm
■Width 70.0mm
■Height 46.0mm
■Chassis MA-020-N
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P
■Weight 193g

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 172.5mm
■Width 75.0mm
■Height 49.0mm
■Wheelbase 98.0mm （LL）
■Tread F:64.5mm R:62.0mm
■Chassis RWD (MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm (for RWD)
■Rear Wheel Offset Wide +1.5mm (for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 172.5mm
■Width 75.0mm
■Height 49.0mm
■Wheelbase 98.0mm （LL）
■Tread F:64.5mm R:62.0mm
■Chassis RWD (MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm (for RWD)
■Rear Wheel Offset Wide +1.5mm (for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

Spare parts for the KE21SP engine.

■ Input voltage USB Type-C 5-12V (Power supply with output 3A or more compatible with Quick Charge 2.0 / 3.0 and Power Delivery is recommended)
* Please purchase the charging adapter separately.
■ Body size 120x92x34 (mm)
■ Weight 195g
■ Number of charging 1-4
■ Compatible batteries NiMH, NiZn, Li-Ion, LiHV, LiFe AAA type (AAA), AA type (AA), 10440, 10500, 12500 , 13500, 13650, 14500, 14650, 16650, 17650, 17670, 18650, 18700, 20650, 20700, 21700, 22650, 26650, 26700 * Batteries longer than 70mm cannot be used

Internal resistance: 0.0011Ω
Continuous maximum current: 60A
Instantaneous maximum current: 80A
Maximum KV value (2S): 13.5T 3200KV
Driving mode: Forward / brake / forward / brake / reverse
Input voltage: 7.2V-11.1V
Compatible motor type: Sensor & Sensorless
BEC output: 6V / 2A
size (mm): 37.5 x 30.8 x 18.7
Weight (g): Approximately 80

■Length 197.3mm
■Width 87.3mm
■Height 89.1mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 234g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1
■Front Tire Diameter Φ42.0mm
■Rear Tire Diameter Φ42.0mm
■Front Tire Width 14.3mm
■Rear Tire Width 14.3mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

<Kit Content>
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

<Required to run>
●4 x AAA batteries for the transmitter
●4 x AAA batteries for chassis （Alkaline or NiMH）

■Length 197.3mm
■Width 87.3mm
■Height 89.1mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 234g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1
■Front Tire Diameter Φ42.0mm
■Rear Tire Diameter Φ42.0mm
■Front Tire Width 14.3mm
■Rear Tire Width 14.3mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

<Kit Content>
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

<Required to run>
●4 x AAA batteries for the transmitter
●4 x AAA batteries for chassis （Alkaline or NiMH）

■Length 155.0mm
■Width 68.0mm
■Height 51.0mm
■Chassis MA-020-N
■Wheelbase 90.0mm（M）
■Tread F : 58.5mm R : 58.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow +1.0mm
■Rear Wheel Offset Narrow +1.0mm
■R/C System Syncro KT-531P
■Weight 193g

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 161.0mm
■Width 67.0mm
■Height 43.0mm
■Chassis MA-020-N
■Wheelbase 90.0mm（M）
■Tread F : 56.5mm R : 56.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow +0.0mm
■Rear Wheel Offset Narrow +0.0mm
■R/C System Syncro KT-531P
■Weight 192g

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 180.0mm
■Width 78.0mm
■Height 40.0mm
■Wheelbase 102.0mm （3L）
■Tread Wide
■Chassis RWD(MR-03)
■Motor Mount LM
■Front Wheel Offset Narrow+1.5mm(for RWD)
■Rear Wheel Offset Wide +-0.0mm(for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels
●Mini pylons

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length  123.5mm
■Width   70～76mm
■Height  35mm
■Motor Mount MM
■Wheelbase   98.0mm (LL)
■Tread F：61.5～65.0mm／R：61.5～65.0mm
■Tires (F/R) φ25×8.5mm (sold separately)/φ25×8.5〜11mm (sold separately)
■Gear Ratio  7.3、6.3、5.5、4.9：1
■Weight 135g (Body / tires / wheels not included, battery included.)
■Motor  KYOSHO SPEED HOUSE XSPEED 85 (KV8500)

■Length 461mm

■Width 195mm(Body width:210mm)
■Wheelbase 260mm
■Tread (F/R) F：167mm／R：167mm
■Tires (F/R) F：φ64×27.7mm／R：φ64×27.7mm
■Gear Ratio 6.54：1
■Weight  1650g (approx.)
■R/C system      Syncro KT-231P+
■Motor      G14L

■Length: 612mm
■Width: 130mm
■Height: 1,135mm
■Weight: 1,050g
■Sail Area: 21.85dm2

■Overall length 177mm
■ Overall width 78mm
■ Overall height 47.5mm
■ Overall weight 130g
■ Wheel base
98mm (LL) ■ Tread F: 67.5mm R: 65.0mm
■ Used chassis RWD (MR-03)
■ Motor mount MM
■ Front wheel offset narrow + 3.0mm (for RWD)
■ Rear wheel offset wide + 3.0mm (for RWD)
■ Used radio Syncro KT-531P

※It is not possible to drive with auto scale alone. In addition, some bodies cannot be mounted depending on the chassis.
※The optional part No. MZW411B friction damper set cannot be installed because it interferes with a part of the body.

Diecast with open/close features.

More photo

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×40mm
■Gear Ratio 1st gear /10.14:1　2nd gear /7.49:1
■Weight 3,650g（approx. ）
■Engine　KE25SP
■Transmitter　Syncro KT-331P

Kit Content

●Pre-assembled chassis installed with 2-ch, 2-servo R/C system and pre-set control linkages
●Pre-painted factory assembled body with decals applied
●Installed KE25SP rear exhaust engine
●Installed polished tuned muffler
●Syncro KT-331P transmitter
●Hex wrenches: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench (large)
●17mm wheel wrench
●Nylon strap (for air cleaner)
●Break in ring
●Bind code

Required to run

●8 x AA batteries for transmitter (4) and receiver (4)
●Fuel
●Engine starting tools (fuel bottle, plug heater)

* You cannot drive with the auto scale alone. In addition, some bodies cannot be mounted due to the chassis.

Diecast with opening features.

■Length 166.0mm
■Width 78.0mm
■Height 44.0mm
■Wheelbase 98.0mm （LL）
■Tread F:65.5mm R:65.0mm
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +2.5mm(for RWD)
■Rear Wheel Offset Wide +3.0mm(for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 177.0mm
■Width 76.5mm
■Height 45.0mm
■Wheelbase 98.0mm （LL）
■Tread F:64.5mm R:64.0mm
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm(for RWD)
■Rear Wheel Offset Wide +2.5mm(for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length: 570mm
■Width: 450mm
■Height: 281mm
■Weight 5,040g
■Wheelbase: 360mm
■Tread F:339mm R:343mm
■Tire (F＆R):164 x 104mm
■Gear Ratio: 8.68：1
■Motor: KSH TORX 8+ kv2300

＜ Readyset Contents ＞
●Pre-assembled chassis with pre-set control linkages
●Factory assembled printed body
2.4GHz Syncro KT-231P+ transmitter
●L-shape hex wrenches: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench
●17mm wheel wrench

＜ Required for Operation ＞
●4 x AA alkaline batteries for transmitter
●Running battery (2 x 7.2v Ni-MH to 2 x7.4v lipo battery)
●Charger
●Stabilized power supply

■Length 570mm
■Width 450mm
■Height 281mm
■Weight 4,990g
■Wheelbase 360mm
■Tread F:339mm R:343mm
■Tires （F & R） φ164×104mm
■Gear Ratio 25.7/19.8/15.6:1
■Engine KE25SP2 with recoil starter

<Readyset Contents>
●Pre-assembled chassis with pre-set control linkages
●Pre-cut and painted body complete with decals applied
●2.4GHz Syncro KT-231P+ transmitter
●L shaped hex wrench (1.5mm, 2.0mm, 2.5mm, 3.0mm)
●Cross wrench (large)
●17mm wheel wrench

<Required for Operation>
●AA-size batteries x 4 for transmitter
●AA-size batteries x 4 for receiver
●Glow fuel for models
●Fuel bottle
●Plug heater

Exquisite finish and realistic appearance. A complete body series that can be enjoyed as a high-quality display that provides the joy of decorating.
* This product is a spare body set and cannot be run. To enjoy driving as an RC model, please purchase a ready set.

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×40mm
■Gear Ratio 8.95：1
■Weight 3,650g（approx. ）
■Motor　KYOSHO SPEED HOUSE TORX8+ brushless motor(kv2300)
■Transmitter　Syncro KT-331P

<Readyset Contents>
●Pre-assembled chassis with 2-channel, 1-servo, ESC R/C system installed
●Pre-painted body complete with decals applied
●KYOSHO SPEED HOUSE TORX8+ brushless motor installed
●KYOSHO SPEED HOUSE BRAINZ 8 ESC installed
●Syncro KT-331P transmitter
●Hexagonal wrench: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench (large)
●17mm wheel wrench

<Required for Operation>
●Battery for chassis
●Charger for battery
●4 x AA-size batteries for transmitter

■Length 490mm
■Width 195mm(Body width:208mm)
■Wheelbase 274mm
■Tread (F/R) F：167mm／R：167mm
■Tires (F/R) F：φ64×27.7mm／R：φ64×27.7mm
■Gear Ratio 6.54：1
■Weight  1650g (approx.)
■R/C system      Syncro KT-231P+
■Motor      G14L

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●Installed 60A waterproof electronic speed controller (forward/brake/reverse)
●+5mm off-set wheel hub (for 200mm width chassis), M4 x 22 wheel screw
●Hexagonal wrench
●Spanner

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

■Length 455mm
■Width（Body width） 200mm（210mm）
■Height　120mm
■Wheelbase 260mm
■Tread (F/R) F：174mm／R：174mm
■Tires (F/R) F：φ64×24.2mm／R：φ64×24.2mm
■Gear Ratio 6.54：1
■Weight 1650g(approx.)
■Syncro KT-231P+ transmitter
■Motor G14L

※Steel made
Old part #IF105

Preglued USA-1 tire and wheel set. Includes 2pcs

Carbon Rear shock tower for the MP10 / MP10 TKI2 / MP10e. Designed to use with MP10TKI2 long shocks. Light weight and durable carbon allows lower CG. The slightly more flex feel allows a different feel than the aluminum shock towers. A great setup option for various tracks.

Carbon front shock tower for the MP10 / MP10 TKI2 / MP10e. Designed to use with MP10TKI2 long shocks. Light weight and durable carbon allows lower CG. The slightly more flex feel allows a different feel than the aluminum shock towers. A great setup option for various tracks

Carbon AMB Holder for the MP9/MP10. made from precision high quality carbon material.

Can be mounted on the FAZER Mk2 series FZ02L-BT / FZ02L VE-BT chassis.
Body accessory parts with plated finish improve scale realism for body shell, protector parts protect the roof when turn over, polycarbonate rear spoiler, decals and masking sheets used for the ready set. Comes with decoration decals for customized body shell you wish. The LED light unit series (#97054) sold separately can be installed in the light buckets.
Finished body size: Approximately 378x154x135mm (excluding mirrors)

Spare parts for the KE21SP2 engine

Back plate for the KE21 SP / KE25SP / KE25SP2 engine. Back plate elimintes the pull start allowing the use of starter boxes. Less friction allows more performance.

φ3×250mm / 4pcs

Spare Parts for SCORPION 2014

Gyro unit for MINI-Z readyset. Compatible with blue board RC units, or green board RC units with a blue marking on the gyro connector.

Correspondence table

Spare center front universal swing shaft for the USA-1. Compatible with the Mad Crusher / FO-XX series.

Spare Bumper/Body mount set for the USA-1 series. Compatible with the Mad Crusher / FO-XX series.

INFERNO MP10 TKI2 Spare parts

Spare part for the Mad Van VE. It can be used on the standard Mad Van(34412T1) as an option. Durable sintered metal materila.

Spare part for the Mad Van VE. It can be used on the standard Mad Van(34412T1) as an option. Durable sintered metal materila.
