■Length 630mm
■Width 402mm
■Height 244mm
■Wheelbase 452mm
■Tread (F/R) 53 / 331mm
■Tire(F/R) Φ130×43mm / Φ140×71mm
■Gear Ratio 16.0：1
■Weight 4000g（with body）
■Motor Orion Vortex 7 brushless

■Length 550mm
■Width 296mm
■Height 150mm
■Wheelbase 330mm
■Tread (F/R) 246mm/248mm
■Tire(F/R) Φ110×44mm/110×44mm
■Gear Ratio 10.95:1
■Weight 2,000g (approx.)
■Motor VORTEX dDRIVE

■Length 177.0mm
■Width 79.5mm
■Height 44.0mm
■Chassis MR-04W-LM
■Wheelbase 102.0mm （3L）
■Tread F:67.5mm R:65.0mm
■Front Wheel Offset Narrow +3.0mm
■Rear Wheel Offset Wide +1.0mm
■Weight 168g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length  167mm
■Width  106mm
■Height  56mm
■Wheelbase 115mm
■Tread (F/R) 89mm/89mm
■Tire(F/R) F37 x 13.5mm/F37 x 18.5mm
■Weight  200g (approx.)
■Motor  130 class
■Battery AAA alkaline x 4
■R/C System KT-531P FHSS 2.4 GHz

＜Readyset Contents＞
●Factory assembled chassis with pre-installed R/C unit
●KT-531P transmitter
●Pre-painted polycarbonate body finished with markings
●Pinion gears (11T, 13T, 15T)
●Spur gears (33T, 35T)
●Pinion gear tool
●Pairing stick
●Wheel wrench
●Spare nuts for wheels

＜Required for operation＞
●AAA alkaline batteries x 4 or NiMH batteries x 4 for chassis
●AAA alkaline batteries x 4 for KT-531P transmitter

• •

    Instruction Manual

※The user manual is not included with this product. You can download the user manual from the following link.

<Kit Content<
●MR-04 EVO2-W-MM Factory assembled chassis with KYOSHO SPEED HOUSE KV5600 brushless motor
●Parts set for changing front tread
●6T・7T・8T・9T Pinion gears
●Wheel wrench
●Tools for pinion gears
●Spare wheel nuts

＜Required for Operation＞
●Transmitter
●Receiver unit (Compatible with EVO/EVO2)
●ASC
●AAA x 4 batteries for chassis
●Batteries for transmitter

●Scale: Approximately 1/28 scale
●Product size：L160 x H50.5 x D73.9（mm）
●Product weight：109g (approx.)
●Package size：W215 × H225 × D115（mm）
●Package weight：Approximately 343g
●Maximum speed: Training mode: 7km/h Racing mode: 10km/h
●Operation distance: approx. 30m
●Frequency: 2.4GHz (12 vehicles can run simultaneously)
●Continuous running time: Approximately 60 minutes (when using new alkaline batteries)
●Target age: 6 years old or older

<Kit Content>
●Main unit
●2.4GHz controller with stopwatch
●Mini pylons (6 pieces)
●Trim adjuster
●Battery holder
●Seal

<Required to run>
●AA-size alkaline batteries x 2 for chassis (Not included)
●AA-size alkaline batteries x 2 for transmitter (Not included)

■Length 168.0mm
■Width 72.0mm
■Height 48.0mm
■Chassis MR-04N-RM
■Wheelbase 90.0mm （M）
■Tread F:59.5mm R:59.0mm
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Wide ±0.0mm
■Weight 169g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 165.0mm
■Width 68.0mm
■Height 53.0mm
■Wheelbase 94.0mm（L）
■Tread F : 56.5mm R : 56.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +-0.0mm
■Rear Wheel Offset Narrow +-0.0mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 370mm
■Width 250mm
■Height 130mm
■Wheelbase 260-263mm
■Tread F:208mm / R:214
■Weight approx 1500g(with 7.2V4000 LiPo）
■Tires F: φ75×20mm / R: φ82×36mm
■Motor 540 class size (sold separately)
■Gear ratio 8.64：1

<Kit Content>
●Kit chassis
●Tire
●Wheel
●Clear body
●Decals
●hexagon wrench
●Cross wrench
●Shock wrench
●Grease
●Shock oil
●Ball Diff Grease

＜Required for Operation＞
●2 channel R/C system
●Servo
servo size：L42xW21xH38mm
●540Motor
●ESC
ESC size：L45xW38xH27mm
●Battery for chassis
Battery size：L140xW47.5xH25mm
●Batteries for transmitter
●Charger for battery
●Paint for body

■Length 202.0mm
■Width 95.0mm(Both ends of the tire)
■Height 96.0mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:77.0mm
■Weight 247.6g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1
■Front Tire Diameter Φ40.5mm
■Rear Tire Diameter Φ40.5mm
■Front Tire Width 18.0mm
■Rear Tire Width 18.0mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

Kit Content
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

Require to run
●4 x AAA batteries for the transmitter
●4 x AAA batteries for chassis （Alkaline or NiMH）

*Combo set is only for offroad application.

■Length 144.3mm
■Width 70.0mm
■Height 56.0mm
■Wheelbase 90.0mm（M）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 144.3mm
■Width 70.0mm
■Height 56.0mm
■Wheelbase 90.0mm（M）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 165.0mm
■Width 71.0mm
■Height 50.0mm
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length　490mm
■Width　307mm
■Height　180mm
■Ground Clearance　28mm
■Wheelbase　325mm (4 settings available by changing rear hub collar position)
■Tread (F/R)　254mm (2 front settings and 3 rear settings available by changing bushes)
■Tire (F/R)　φ116 x 44mm
■Gear Ratio　11.7:1
■Weight　3,370g approx.
■Engine　KE21SP (recoil starter installed/rear exhaust)

<Kit Content>
●Factory assembled chassis installed with R/C system
●Printed pre-cut body complete with coloring
●Pre-installed KE21SP engine with rear exhaust
●Syncro KT-331P transmitter
●1.5, 2.0, 2.5mm Hexagonal wrench
●Cross wrench (small)
●17mm Wheel wrench

<Require to run>
●AAA x 8 alkaline batteries for transmitter
●Fuel
●Starting tools (Fuel bottle, Plug heater)

■Length 165.0mm
■Width 70.0mm
■Height 46.0mm
■Weight 193g
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 163.0mm
■Width 67.0mm
■Height 51.0mm
■Wheelbase 94.0mm（L）
■Tread F : 56.5mm R : 56.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +-0.0mm
■Rear Wheel Offset Narrow +-0.0mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 155.0mm
■Width 70.0mm
■Height 50.0mm
■Wheelbase 90.0mm（M）
■Tread F : 57.5mm R : 57.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow +0.5mm
■Rear Wheel Offset Narrow +0.5mm
■R/C System Syncro KT-531P
■Weight 193g

<Readyset Contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

Option parts for the Fazer Mk2. CNC machined aluminum front hubs allow precise and linerar steering response and smooth suspensionmovement. Allows camber angle adjustments.

Gyro unit for MINI-Z readyset. Compatible with blue board RC units, or green board RC units with a blue marking on the gyro connector.

Correspondence table

※It is not possible to drive with auto scale alone. In addition, some bodies cannot be mounted depending on the chassis.
※The separately sold LED light unit set (No.MZW429R) cannot be installed on the IMPREZA 22B-STi.

■Length 462mm
■Width 200mm(Body width * Excluding mirrors)
■Height 136mm
■Chassis Height 8mm(approx.)
■Wheelbase 260mm
■Tread (F/R)  167mm
■Tires (F/R)  φ64×27.7mm
■Gear Ratio 6.54：1
■Weight  1650g (approx.)
■R/C system &; Syncro KT-231P+
■Motor G14L

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●Hexagonal wrench
●Spanner
●Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

■Length 185.8mm
■Width 83mm
■eight 104.0mm
■Chassis Type MX-01
■Wheel Base 110mm
■Tread F/R:72.7mm
■Weight 248.6g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1 　
■Front Tire Diameter Φ42.0mm
■Rear Tire Diameter Φ42.0mm
■Front Tire Width 14.3mm
■Rear Tire Width 14.3mm
■Battery 4 x AAA alkaline
■Transmitter Syncro KT-531P
■Speed Approx. 3.3km/h〜6.6km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 50 mins

Kit Content
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

High Performance Servo with Brushless Motor (01102359-3)

FEATURES:
– Suitable for RC cars 1/10 scale on/off road and 1/8 scale on/off road.
– Programmable/HV Brushless Servo.
– Custom New high power Brushless Motor.
– Supports SR mode with T4PM/P, T7PX/R, T10PX.
– Supports UR mode with T10PX.
– Programmable and compatible with S.Bus and S.Bus2 systems.
– Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
– Upper/middle/bottom: Aluminum Case

■Length 472mm
■Width 350mm
■Height 198mm
■Wheelbase 295mm
■Tread F/R 278mm
■Tires（F & R） φ128 x 70mm
■Gear Ratio 15.22：1
■Weight 3,610g (approx.)
■Motor TORX10L Brushless Motor kv2850

<Readyset Contents>
●Factory assembled chassis complete with control linkages
●Pre-cut and painted body complete with decals applied
●2.4GHz Syncro KT-231P+ transmitter
●1.5mm/2.0mm/2.5mm L shaped hex wrench
●Cross wrench
●4/5/5.5/7/10mm Integrated spanner

<Required for Operation>
●AA-size batteries x 4 for transmitter
●Battery for driving (2-3S LiPo battery *Installable battery size 143x47x30mm)
●Charger for LiPo battery

■Length (Including body) 456mm
■Width205mm (Excluding mirrors)
■Chassis Height 8mm (approx.)
■Height (Including body) 138mm
■Wheelbase 260mm
■Tread（F／R） 174mm
■Tires（F／R） φ66×25mm
■Gear Ratio 6.54：1
■Weight 約1650g
■R/C system &; Syncro KT-231P+
■Motor G14L

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●Hexagonal wrench
●Spanner
●Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

■Length 161.0mm
■Width 72.0mm
■Height 52.0mm
■Wheelbase 94.0mm（L）
■Tread F : 61.5mm R : 59.0mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide +-0.0mm
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length  563mm
■Width  414mm
■Wheelbase 384-389mm
■Tread（F/R） 353mm(approx)
■Tires（F/R） For stadium track(Sold separately)
■Gear Ratio 14.12:1
■Weight  4,200g (approx)
■Transmitter 2ch or more 1 servo /1 ESC(Sold separately)

＜Kit Contents＞
●Unassembled chassis kit
●Clear body
●Decals
● Hexagonal wrench (1.5mm、2.0mm、2.5mm、3.0mm)
●Cross wrench
●17mm wheel wrench

＜Required for Operation＞
●2ch～3ch transmitter & receiver for R/C cars
●Servo (high torque servo recommended)
●Motor(for 1/8)
●ESC
●Battries for chassis(7.4vLipox2 Recommendation）
●Charger
●Stadium truck tire
●Wheel
●Inner sponge
●Color for body painting

Rocky terrain for the MINI-Z 4x4. A set of 5 pieces of 480 x 480 x 103mm terrain. Making a square with four pieces and putting the 5th one on the center of the square will make a 960 x 960 x 156mm terrain, and you can enjoy wide variety of terrain by rotating each piece. Even larger terrain can be made using multiple sets.

■Length 185.8mm
■Width 83mm
■eight 104.0mm
■Chassis Type MX-01
■Wheel Base 110mm
■Tread F/R:72.7mm
■Weight 238g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1 　
■Front Tire Diameter Φ42.0mm
■Rear Tire Diameter Φ42.0mm
■Front Tire Width 14.3mm
■Rear Tire Width 14.3mm
■Battery 4 x AAA alkaline
■Transmitter Syncro KT-531P
■Speed Approx. 3.3km/h〜6.6km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

<Kit Content>
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

<Require to run>
●4 x AAA batteries for the transmitter
●4 x AAA batteries for chassis （Alkaline or NiMH）

■Length 167.0mm
■Width 70.0mm
■Height 52.0mm
■Wheelbase 98.0mm（LL）
■Tread F : 59.5mm R : 59.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Narrow +1.5mm
■R/C System Syncro KT-531P
■Weight 193g

<Readyset Contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length 177.0mm
■Width 76.5mm
■Height 45.0mm
■Wheelbase 98.0mm （LL）
■Tread F:64.5mm R:64.0mm
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm(for RWD)
■Rear Wheel Offset Wide +2.5mm(for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

Compact & High performance 「Starter Box」

CNC machined 3mm thick carbon shock stay. The strength is significantly improved compared to the normal FRP product

Spare parts for Optima Mid

■Length 455mm
■Width（Body width） 200mm（210mm）
■Height　120mm
■Wheelbase 260mm
■Tread (F/R)：174mm
■Tires (F/R)：φ63.2×24.2mm
■Gear Ratio 6.54：1
■Weight 1650g(approx.)
■Syncro KT-231P+ transmitter
■Motor G14L

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●Hexagonal wrench
●Spanner
● Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

■Length 167.5mm
■Width 70.0mm
■Height 50.0mm
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Tire F : Φ25.0mm×8.5mm R : Φ25.0mm×8.5mm
■Gear ratio 7.23、6.38、5.71、5.97、5.34、4.97、4.5：1
■Front Wheel Offset Narrow+1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P
■Weight 193g

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

Exquisite finish and realistic appearance. A complete body series that can be enjoyed as a high-quality display that provides the joy of decorating.
* This product is a spare body set and cannot be run. To enjoy driving as an RC model, please purchase a ready set.

Steering plate set. 5 kinds of toe angles can be selected for wider setup range.

Recommended Stand for working on the damper. The magnet plate on the front will help preventing to lost screws.

LiPo power at a budget price from ANTIX by LRP.

These RC car LiPos are ideal for hobby and amateur drivers looking for power and durability at a budget price.

The special "stickpack" shape is based on the NiMh packs for which many chassis were designed.
Also for the new release of vintage models you get perfectly fitting batteries of the latest technology with 134mm length and additionally slightly offset cable exit, so the battery posts of your chassis do not get in the way.
Equipped with a robust hard case, these 2S LiPo batteries are suitable for tough On- and Offroad use.

■Length 197.3mm
■Width 87.3mm
■Height 89.1mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 234g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1
■Front Tire Diameter Φ42.0mm
■Rear Tire Diameter Φ42.0mm
■Front Tire Width 14.3mm
■Rear Tire Width 14.3mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

<Kit Content>
●Complete chassis with built-in electronics.
●Factory-painted body complete with many fine details
●KT-531P 2.4GHz transmitter
●Pinion gear set（10T、12T、14T、16T、18T、20T）
●3 types of pinion gear spacers

■Length 180.0mm
■Width 78.0mm
■Height 40.0mm
■Wheelbase 102.0mm （3L）
■Tread Wide
■Chassis RWD(MR-03)
■Motor Mount LM
■Front Wheel Offset Narrow+1.5mm(for RWD)
■Rear Wheel Offset Wide +-0.0mm(for RWD)
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted plastic body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Front suspension adjustment spacers
●Pinion gears 6T, 7T, 8T, 9T
●Wheel wrench
●Pinion gear tool
●Spare nuts
●Pairing stick
●Tires, wheels
●Mini pylons

<Required for Operation>
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length: 612mm
■Width: 130mm
■Height: 1,135mm
■Weight: 1,050g
■Sail Area: 21.85dm2

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×40mm
■Gear Ratio 1st gear /10.14:1　2nd gear /7.49:1
■Weight 3,650g（approx. ）
■Engine　KE25SP
■Transmitter　Syncro KT-331P

Kit Content

●Pre-assembled chassis installed with 2-ch, 2-servo R/C system and pre-set control linkages
●Pre-painted factory assembled body with decals applied
●Installed KE25SP rear exhaust engine
●Installed polished tuned muffler
●Syncro KT-331P transmitter
●Hex wrenches: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench (large)
●17mm wheel wrench
●Nylon strap (for air cleaner)
●Break in ring
●Bind code

Required to run

●8 x AA batteries for transmitter (4) and receiver (4)
●Fuel
●Engine starting tools (fuel bottle, plug heater)

■Length: 570mm
■Width: 450mm
■Height: 281mm
■Weight 5,040g
■Wheelbase: 360mm
■Tread F:339mm R:343mm
■Tire (F＆R):164 x 104mm
■Gear Ratio: 8.68：1
■Motor: KSH TORX 8+ kv2300

＜ Readyset Contents ＞
●Pre-assembled chassis with pre-set control linkages
●Factory assembled printed body
2.4GHz Syncro KT-231P+ transmitter
●L-shape hex wrenches: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench
●17mm wheel wrench

＜ Required for Operation ＞
●4 x AA alkaline batteries for transmitter
●Running battery (2 x 7.2v Ni-MH to 2 x7.4v lipo battery)
●Charger
●Stabilized power supply

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×40mm
■Gear Ratio 8.95：1
■Weight 3,650g（approx. ）
■Motor　KYOSHO SPEED HOUSE TORX8+ brushless motor(kv2300)
■Transmitter　Syncro KT-331P

<Readyset Contents>
●Pre-assembled chassis with 2-channel, 1-servo, ESC R/C system installed
●Pre-painted body complete with decals applied
●KYOSHO SPEED HOUSE TORX8+ brushless motor installed
●KYOSHO SPEED HOUSE BRAINZ 8 ESC installed
●Syncro KT-331P transmitter
●Hexagonal wrench: 1.5, 2.0, 2.5, 3.0mm
●Cross wrench (large)
●17mm wheel wrench

<Required for Operation>
●Battery for chassis
●Charger for battery
●4 x AA-size batteries for transmitter

■Length 490mm
■Width 195mm(Body width:208mm)
■Wheelbase 274mm
■Tread (F/R) F：167mm／R：167mm
■Tires (F/R) F：φ64×27.7mm／R：φ64×27.7mm
■Gear Ratio 6.54：1
■Weight  1650g (approx.)
■R/C system      Syncro KT-231P+
■Motor      G14L

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●Installed 60A waterproof electronic speed controller (forward/brake/reverse)
●+5mm off-set wheel hub (for 200mm width chassis), M4 x 22 wheel screw
●Hexagonal wrench
●Spanner

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

Can be mounted on the FAZER Mk2 series FZ02L-BT / FZ02L VE-BT chassis.
Body accessory parts with plated finish improve scale realism for body shell, protector parts protect the roof when turn over, polycarbonate rear spoiler, decals and masking sheets used for the ready set. Comes with decoration decals for customized body shell you wish. The LED light unit series (#97054) sold separately can be installed in the light buckets.
Finished body size: Approximately 378x154x135mm (excluding mirrors)

■Length   486mm
■Width  （Body width） 190mm（200mm）
■Height 144mm
■Wheelbase   274mm
■Tread (F/R)     F：174mm／R：174mm
■Tires (F/R)     F：φ66×25mm／R：φ66×25mm
■Gear Ratio     6.5：1
■Weight        1650g (approx.)
■R/C system      Syncro KT-231P+
■Motor      G14L

■Length 177mm
■Width 78mm
■Height 47.5mm
■Weight 130g
■Wheelbase 98mm （LL）
■Tread F : 67.5mm R : 65.0mm
■Chassis RWD (MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +3.0mm (for RWD)
■Rear Wheel Offset Wide +3.0mm (for RWD)
■R/C System Syncro KT-531P

■Length　1300mm
■Width　1600mm
■Weight　EP/2,550g (approx.), GP/2,450g (approx.)
■Motor　600-1000W BL Motor (sold separately)
■Engine　2 Cycle 40-46 class engine (sold separately)
■Battery (EP)　14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area　 44dm2
■Wing Loading　55.7-55.9g/dm2
■Airfoil 　Original semi-symmetrical
■Propeller size　D11 x P7-D12 x P8 (sold separately)
■Tire size　Nose 60mm / Main 60mm
■Dihedral　2.5°
■Side Thrust　2°
■R/C system (EP)　4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP)　4ch, 5 servo (sold separately)

■Length: 1,600mm
■Width: 1,800mm
■Weight : (EP) 3,900g　(GP) 3,700g
■Motor(EP): 800-1200W class backplate mounted outrunner brushless (sold separately)
■Engine (GP): 2-cycle 60-65 class (sold separately)
■Battery (EP): 14.8V 5,000ｍAh Li-Po (sold separately)
■Wing Area: 60.6dm2
■Wing Load : 61.0-64.3g/dm2
■Wing Type : Original semi-symmetrical
■Propeller : D12xP6-D14xP8 (sold separately)

Roll damper for R246-1361 and MZ217 MM2 Motor Mount.
Features:
- Blue anodized precision machined aluminum with shiny finished edges
- Recommended using with R246-1360 oil damper
- Can be assembled in L, LL and 3L wheelbases

■Channels 3
■Frequency 2.4GHz
■Modulation System FHSS telemetry system
■Size Transmitter：W105mm x L175mm x H230mm
Receiver：W37.9mm x L22.5mm x H13mm
■Weight  Transmitter：390g　/　Receiver：5.7g
■ESC Power Source　2-3S Li-Po/5-9cellNi-Mh
■ESC Continuous current 60A
■Range 100m

■Length  167mm
■Width  106mm
■Height  56mm
■Wheelbase 115mm
■Tread (F/R) 89mm/89mm
■Tire(F/R) F37 x 13.5mm/F37 x 18.5mm
■Weight  200g (approx.)
■Motor  130 class
■Battery AAA alkaline x 4
■R/C System KT-531P FHSS 2.4 GHz

■Length  123.5mm
■Width   70～80mm
■Height  35mm
■Wheelbase   98.0mm (LL)
■Tread F：61.5～69.0mm／R：61.5～69.0mm
■Motor Mount MML
■Tires (F/R) φ25×8.5mm (sold separately)/φ25×8.5〜11mm (sold separately)
■Gear Ratio  7.3、6.3、5.5、4.9：1
■Weight 141g (Body / tires / wheels not included, battery included.)
■Motor  KYOSHO SPEED HOUSE 「XSPEED 85」KV8500

Mini Z Body Shell

Spare part for MINI-Z RWD series & FWD series.
Features steering / throttle trim as well as dual rate adjustment of steering angle
and control the flashing speed of optional LEDs.
The sponge grip of the steering wheel provides comfortable fit for precision control feel.
In addition, the transmitter has a Training Mode feature which limits speed
of the car for easy learning.
(default setting at the time of shipment is Training Mode)

This set only come with Controller, doesn't include any receiver.

Exquisite finish and realistic appearance. A complete body series that can be enjoyed as a high-quality display that provides the joy of decorating.
* This product is a spare body set and cannot be run. To enjoy driving as an RC model, please purchase a ready set.

General-purpose parts

Front shock stay (5.0mm thick) for the INFERNO NEO 3.0 Readyset

Spare parts for the MP10T

Spare parts for the Nitro Tracker

• Use a WORLD CHAMPION Tire like the Pros
• Available in M3, M4 and S3 Compound
• Extra Tread Wear for Your Money
• Long Lasting Tread yet still Fast and Agile
• Incredible Performance to Cost Ratio
• Perfect for Extreme Wear Conditions with Little Dust
• Improved Traction with S-Compound Technology
• Long lasting Closed Cell Inserts Included
• Made in the USA, since 1982 - Read about Pro-Line Racing's History

• Use a WORLD CHAMPION Tire like the Pros
• Available in M3, M4 and S3 Compound
• Extra Tread Wear for Your Money
• Long Lasting Tread yet still Fast and Agile
• Incredible Performance to Cost Ratio
• Perfect for Extreme Wear Conditions with Little Dust
• Improved Traction with S-Compound Technology
• Long lasting Closed Cell Inserts Included
• Made in the USA, since 1982 - Read about Pro-Line Racing's History

EX-2 with Drop Extension Steering Unit2(ST2)

[Specifications]

#Dimensions: 240×163×107mm 　
#Weight: 528g ( Not included battery)
#Current: 150mA RO3/AAA/UM4 battery x 4
#Using time: 6hours ( It may change by a kind of battery in use.）
#40 Model Memories.
#Micro receiver KR-211FH included.
#Other Compatible receivers: KR-418FH,KR-415FHD,KR-413FH,KR-241FH,KR-211FH,KR-212FHG.

*This products does not include the Manual in the package. Please download manual from here. (Manual is same as EX-RR ver2.0 software. But Grip Unit is different at EX-RR and  EX-2, please attention this difference.)

Made in Japan.

A pair of pre-glued tires and wheels assembled with a weight inside. Using on the front ensures excellent traction for hill climbing.

■Length 1300mm
■Width 1600mm
■Weight EP/2,550g (approx.), GP/2,450g (approx.)
■Motor 600-1000W BL Motor (sold separately)
■Engine 2 Cycle 40-46 class engine (sold separately)
■Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area 44dm2
■Wing Loading 55.7-55.9g/dm2
■Airfoil Original semi-symmetrical
■Propeller size D11 x P7-D12 x P8 (sold separately)
■Tire size Nose 60mm / Main 60mm
■Dihedral 2.5°
■Side Thrust 2°
■R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP) 4ch, 5 servo (sold separately)

■Length 174.0mm
■Width 75.0mm
■Height 45.5mm
■Wheelbase 98.0mm （LL）
■Tread Wide
■Chassis RWD（MR-03）
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P

■Length 1400mm
■Width 1600mm
■Weight EP/2,550g (approx.), GP/2,450g (approx.)
■Motor 600-1000W BL Motor (sold separately)
■Engine 2 Cycle 40-46 class engine (sold separately)
■Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area 44dm2
■Wing Loading 55.7-55.9g/dm2
■Airfoil Original semi-symmetrical
■Propeller size D11 x P7-D12 x P8 (sold separately)
■Tire size Nose 60mm / Main 60mm
■Dihedral 2.5°
■Side Thrust 2°
■R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP) 4ch, 5 servo (sold separately)

■Length 1400mm
■Width 1600mm
■Weight EP/2,550g (approx.), GP/2,450g (approx.)
■Motor 600-1000W BL Motor (sold separately)
■Engine 2 Cycle 40-46 class engine (sold separately)
■Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area 44dm2
■Wing Loading 55.7-55.9g/dm2
■Airfoil Original semi-symmetrical
■Propeller size D11 x P7-D12 x P8 (sold separately)
■Tire size Nose 60mm / Main 60mm
■Dihedral 2.5°
■Side Thrust 2°
■R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP) 4ch, 5 servo (sold separately)

Meet the small brother of the successful Pulsar Pro charger. The Pulsar Sport has everything that you need for your battery management. The integrated power supply allows you to directly connect it either to
a AC wall socket or to DC sources like car batteries. You don’t need a separate power supply anymore.

Of course, the currently highly sought after HV LiPo battery packs with up to 8.7V (2S) charging are no problem for the Pulsar Sport. It supports LiPo HV charging, making it fully prepared for any future tasks.

Like with all current LRP chargers, the Pulsar Sport also offers a USB charge port (5V/1.0A) that is suitable for smartphones and MP3 players.

■Length 181.0mm
■Width 78.0mm
■Height 40.0mm
■Wheelbase 102.0mm （3L）
■Tread Wide
■Chassis RWD（MR-03）
■Motor Mount LM
■Front Wheel Offset Narrow +2.7mm
■Front Wheel Offset Wide +0.8mm
■R/C System Syncro KT-531P

■Length 660mm ■Width 160mm ■Height 325mm ■Weight 1,500g approx. ■Motor 540-class G24 motor with water-cooling jacket ■Screw D31 x P1.4 (polycarbonate) ■Charging Time 8 hours approx. 16km/h approx. ■Operation time 7 min approx

■Length 165.0mm
■Width 70.0mm
■Height 46.0mm
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P

＜Chassis＞
■MINI-Z MR-03W-MM
＜Technical Data＞
■Wheel Base：LL（98mm）
■Wheel Off Set：F:N+1.5 R:W+1.5
■Wheel Width：F：8.5mm（N） / R：11mm（W）

■Length 410mm
■Width 300mm
■Height 175mm
■Wheelbase 270mm
■Tread (F/R) 230mm/230mm
■Tires (F & R) φ110×70mm
■Gear Ratio 11.27:1
■Motor G22（22ターン）
■Weight 1900g (approx.)
