Spare parts for the INFERNO NEO 3.0

Optional parts for the INFERNO MP10/MP9e Evo.
New setting weights by 10g and 20g which can be installed the main chassis.
Can be adjusted the weights in 10g/20g/30g/40g by weights combination.
Fixing by screws and nylon nut which prevents falling off when driving.

Optional parts for the INFERNO MP10/MP9e Evo.
New setting weights by 10g and 20g which can be installed the main chassis.
Can be adjusted the weights in 10g/20g/30g/40g by weights combination.
Fixing by screws and nylon nut which prevents falling off when driving.

※Spare parts for IGW008 2-Speed Transmission Set (Shoe Type/GT)

Option Parts for INFERNO GT2 Type-R.

Optional parts for the INFERNO MP10/MP9e Evo.
New setting weights by 10g and 20g which can be installed the main chassis.
Can be adjusted the weights in 10g/20g/30g/40g by weights combination.
Fixing by screws and nylon nut which prevents falling off when driving.

CNC machined aluminum hub carrier for the MP10.
Increases durability and rigitity. Includes bushings for bearing protection.

Spare Parts for RB6. 6

Body shell for Mini Z

Body Shell for Mini Z

■Length　418.5mm
■Width　321mm
■Height　194mm
■Weight 2,650g(approx.)
■Wheelbase　298.5mm
■Tread （F/R）　265mm
■Tires (F/R interchangeable)　φ120×56mm
■Gear Ratio　Forward (1st) 20.9:1 / (2nd) 13.9:1
                        Reverse (1st) 24.1:1 / (2nd) 16.0:1
■Engine　KE15SP with recoil

■Length 545mm
■Width 383mm
■Height 248mm
■Wheelbase 360mm
■Tread 312mm
■Tires （F & R） φ155 x 70.5mm
■Gear Ratio 25.7/19.8/15.6:1
■Weight 4,200g (approx.)
■Engine KE25SP

■Length 545mm
■Width 383mm
■Height 248mm
■Wheelbase 360mm
■Tread 312mm
■Tires（F & R） φ155 x 70.5mm
■Gear Ratio 8.68：1
■Weight 4,650g (approx.)
■Motor KYOSHO SPEED HOUSE・TORX 8 Brushless Motor

■Length 168.0mm
■Width 79.0mm
■Height 46.5mm
■Wheelbase 98.0mm （LL）
■Tread F:65.5mm R:65.0mm
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow　+2.0mm(for RWD)
■Rear Wheel Offset Wide +3.0mm(for RWD)
■R/C System Syncro KT-531P

■Length 168.0mm
■Width 79.0mm
■Height 46.5mm
■Wheelbase 98.0mm （LL）
■Tread F:65.5mm R:65.0mm
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow　+2.0mm(for RWD)
■Rear Wheel Offset Wide +3.0mm(for RWD)
■R/C System Syncro KT-531P

■Length  575mm
■Width  428mm
■Wheelbase 381-386mm
■Tread（F/R） 353mm／353mm
■Tires（F/R） For stadium track(not included)
■Gear Ratio 16.3:1
■Weight  3,870g approx.
■Engine .21 ～ .28 classes(not included)
■Transmitter 2ch or more 2 servo(not included)

■Length 395mm
■Width 249mm
■Height 148mm
■Wheelbase 277mm
■Tread（F/R） F：221mm/R：201mm
■Tires（F/R） Sold separately
■Gear Ratio 1st Deceleration：Spur 76T／Pinion Gear sold separately 2nd Deceleration：2.6：1

Spare linkage set for the Inferno MP10T. Compatible with the MP9 / MP10.

Spare parts for the MP10T

Specially designed case for organizing tires and wheels of the MINI-Z. Included stickers allow you to identify the tire hardness without opening the case.

Spare parts for the TURBO OPTIMA.
Optional parts for the OPTIMA and JAVELIN.

New IFMAR legal wheels with 5mm wheel shaft diameter. The wheel is 1mm outwards complying with the regulations. 2mm narrower than the previous configuration.

■Length 162.0mm
■Width 70.8mm
■Height 48.5mm
■Wheelbase 94.0mm （L）
■Tread F:59.5mm R:58.6mm
■Chassis RWD(MR-03)
■Motor Mount RM
■Front Wheel Offset Narrow　+1.5(for RWD)
■Rear Wheel Offset Wide -0.8mm(for RWD)
■R/C System Syncro KT-531P

■Length 162.0mm
■Width 70.8mm
■Height 48.5mm
■Wheelbase 94.0mm （L）
■Tread F:59.5mm R:58.6mm
■Chassis RWD(MR-03)
■Motor Mount RM
■Front Wheel Offset Narrow　+1.5(for RWD)
■Rear Wheel Offset Wide -0.8mm(for RWD)
■R/C System Syncro KT-531P

Body shell for Mini-Z

Body shell for Mini-Z

■Length 166.5mm
■Width 75.0mm
■Height 44.0mm
■Wheelbase 98.0mm （LL）
■Tread Wide
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow+1.5mm(for RWD)
■Rear Wheel Offset Wide +1.5mm(for RWD)
■R/C System Syncro KT-531P

■Length 166.5mm
■Width 75.0mm
■Height 44.0mm
■Wheelbase 98.0mm （LL）
■Tread Wide
■Chassis RWD(MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow+1.5mm(for RWD)
■Rear Wheel Offset Wide +1.5mm(for RWD)
■R/C System Syncro KT-531P

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×48mm
■Gear Ratio 8.95：1
■Weight 3,650g（approx. with body）
■Motor　KYOSHO SPEED HOUSE TORX8 brushless motor
■Transmitter　Syncro KT-331P

■Length 515mm
■Width 310mm
■Height 135mm
■Wheelbase 360mm
■Tread（Ｆ／Ｒ） 262mm／265mm
■Tire（Ｆ／Ｒ） Φ97mm ×40mm
■Gear Ratio 1st gear /10.14:1　2nd gear /7.49:1
■Weight 3,650g（approx. with body）
■Engine　KE25SP
■Transmitter　Syncro KT-331P

Kyosho 1/64 Nissan GT-R 50th Anniversary 4 cars set (R32, R33, R34, R35)

■Length 158.0mm
■Width 71.8mm
■Height 44.5mm
■Wheelbase 94.0mm （L）
■Tread Narrow
■Chassis RWD (MR-03)
■Motor Mount RM
■Front Wheel Offset Narrow +1.0mm (for RWD)
■Rear Wheel Offset Wide +1.5mm (for RWD)
■R/C System Syncro KT-531P

Length　167.0mm
Width　70.0mm
Height　52.0mm
Wheelbase　98(LL)mm
Tread (F/R)　59.5mm／59.5mm
Tire(F/R)　F8.5 mm／F8.5 mm (drift tires)
Gear Ratio　7.23, 6.38, 5.71, 5.97, 5.34, 4.97, 4.5 : 1
Weight　193g (approx.)
Motor　130 class

■Length: 370mm
■Width: 244mm
■Height: 106mm
■Wheelbase: 260-263mm
■Tread (F/R): 206mm / 208mm
■Tire(F/R): 75f x 20mm / 82f x 36mm
■Gear Ratio: 8.64:1
■Weight: approx. 1,500g
■Motor: 540 class size

■Length 177.0mm
■Width 76.0mm
■Height 44.0mm
■Wheelbase 98.0mm（LL）
■Tread F:64.5mm R:62.0mm
■Chassis RWD（MR-03）
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide ++1.5mm
■R/C System Syncro KT-531P

■Length 161.0mm
■Width 72.0mm
■Height 52.0mm
■Wheelbase 94.0mm（L）
■Tread F : 61.5mm R : 59.0mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +2.5mm
■Front Wheel Offset Wide +-0.0mm
■R/C System Syncro KT-531P

■Length 169.0mm
■Width 73.0mm
■Height 49.0mm
■Wheelbase 90.0mm（M）
■Tread F : 61.5mm R : 59.0mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +2.5mm
■Front Wheel Offset Wide +-0.0mm
■R/C System Syncro KT-531P

■Length 496mm
■Width 307mm
■Height 189mm
■Wheelbase 323～328mm
■Tread (F/R) 258mm／261mm
■Tire (F/R) φ115×44mm／φ115×44mm
■Gear Ratio 12.7：1
■Weight 3,550g (approx.)
■Transmitter 2.4GHz Syncro KT-231P+

■Length 496mm
■Width 307mm
■Height 189mm
■Wheelbase 323～328mm
■Tread (F/R) 258mm／261mm
■Tire (F/R) φ115×44mm／φ115×44mm
■Gear Ratio 12.7：1
■Weight 3,550g (approx.)
■Transmitter 2.4GHz Syncro KT-231P+

■Length 410mm
■Width 300mm
■Height 175mm
■Wheelbase 270mm
■Tread (F/R) 230mm/230mm
■Tires (F & R) φ110×70mm
■Gear Ratio 11.27:1
■Motor G22（22ターン）
■Weight 1900g (approx.)

■Length 410mm
■Width 300mm
■Height 175mm
■Wheelbase 270mm
■Tread (F/R) 230mm/230mm
■Tires (F & R) φ110×70mm
■Gear Ratio 11.27:1
■Motor G22（22ターン）
■Weight 1900g (approx.)

■Length: 900mm
■Width: 187mm
■Height: 140mm
■Weight: 1,780g (when 14.8V-4000mAh installed)
■Motor: Pre-installed KYOSHO SPEED HOUSE TORX M4 Brushless water-cooled motor (40x68mm, KV2000)
■Battery: 4 cell 14.8V 3600-4000mAh LiPO (Super Plug specification, sold separately)
■Propeller: Carbon reinforced nylon D40 x P1.4 (3-blade)
■ESC: Pre-installed KYOSHO SPEED HOUSE 120A KA120-91WC water-cooled, waterproof brushless ESC
■Servo: KS-4031-06W

■Length: 945mm
■Width: 230mm
■Weight: 2,350g
■Motor: KYOSHO SPEED HOUSE TORX M6 water-cooled brushless motor (40x68mm, KV1250)
■Battery: 2 x 3 cell 11.1V-3600-4000mAh LiPo battery (Super Plug specification, sold separately)
■R/C System: Perfex KT-231P+
■Propeller: D40×P1.4（3-blade）
■ESC : KYOSHO SPEED HOUSE KA120-91WC 120A water-cooled, waterproof brushless ESC

1,000 limited

■全長 117.7mm
■全幅 70～76mm
■全高 35mm
■ホイールベース 98.0mm（LL）
■トレッドF：61.5～63.0mm／R：61.5～63.0mm
■モーターマウント MM2
■タイヤ（F／R） φ25×8.5mm（別売）／φ25×8.5〜11mm（別売）_
■ギヤレシオ 7.3、6.3、5.5、4.9：1
■全備重量 約135g （ボディなし）
■モーター KYOSHO SPEED HOUSE / XSPEED 56 (5600KV)

＜Chassis＞
■MINI-Z MR-03W-MM
＜Technical Data＞
■Wheel Base：LL（98mm）
■Wheel Off Set：F:N+1.5 R:W+1.5
■Wheel Width：F：8.5mm（N） / R：11mm（W）

＜Chassis＞
■MINI-Z MR-03W-MM
＜Technical Data＞
■Wheel Base：LL（98mm）
■Wheel Off Set：F:N+1.5 R:W+1.5
■Wheel Width：F：8.5mm（N） / R：11mm（W）

Option parts for the MP10T (for Front Shock)

Option parts for the MP10T (for Front Shock)

■Length　163mm
■Width　105mm
■Height　46mm
■Wheelbase　115mm
■Tread（Ｆ/Ｒ）　89mm/89mm
■Tires（Ｆ/Ｒ）　Sold Separately
■Weight　200g approx.
■Motor　SPEED HOUSE XSPEED 85 (8500KV)

＜Chassis＞
■MINI-Z MR-03W-MM
＜Technical Data＞
■Wheel Base：LL（98mm）
■Wheel Off Set：F:N+1.5 R:W+1.5
■Wheel Width：F：8.5mm（N） / R：11mm（W）

Spare parts for the FW06

＜Chassis＞
■MINI-Z MA-020-N
＜Technical Data＞
■Wheel Base：M（90mm）
■Wheel Off Set：F:N+2.5 R:W+-0.0
■Wheel Width：F：8.5mm（Drift） / R：11.0mm（Drift）

Option Parts for SCORPION 2014

■Length 165.0mm
■Width 70.0mm
■Height 46.0mm
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P

■Length 165.0mm
■Width 70.0mm
■Height 46.0mm
■Wheelbase 94.0mm（L）
■Tread F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P

■Length 383mm
■Width 323mm
■Height 200mm
■Wheelbase 273mm
■Tread (F/R) 250mm/250mm
■Tires (F & R) φ110×70mm
■Gear Ratio 11.69:1
■Motor 550 size G14L
■Weight 2,050g (approx.)(When using 7.2V3600 NiMH)

■Length 460mm
■Width 200mm
■Wheelbase 260mm
■Tread (F/R) F：184mm／R：184mm
■Tires (F/R) F：φ66×25mm／R：φ66×25mm
■Gear Ratio 6.5：1
■Weight  1620g (approx.)
■R/C system      Syncro KT-231P+
■Motor      G14L

■Length 660mm ■Width 160mm ■Height 325mm ■Weight 1,500g approx. ■Motor 540-class G24 motor with water-cooling jacket ■Screw D31 x P1.4 (polycarbonate) ■Charging Time 8 hours approx. 16km/h approx. ■Operation time 7 min approx.

■Length 660mm ■Width 160mm ■Height 325mm ■Weight 1,500g approx. ■Motor 540-class G24 motor with water-cooling jacket ■Screw D31 x P1.4 (polycarbonate) ■Charging Time 8 hours approx. 16km/h approx. ■Operation time 7 min approx

Spare parts for the Fazer Mk2 Touring Car

■Length 193mm
■Width 84mm
■Height 90.0mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 242g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                     39.60：1/34.65：1/34.65：1
■Front Tire Diameter Φ37.0mm
■Rear Tire Diameter Φ37.0mm
■Front Tire Width 12mm
■Rear Tire Width 12mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

■Length 181.0mm
■Width 78.0mm
■Height 40.0mm
■Wheelbase 102.0mm （3L）
■Tread Wide
■Chassis RWD（MR-03）
■Motor Mount LM
■Front Wheel Offset Narrow +2.7mm
■Front Wheel Offset Wide +0.8mm
■R/C System Syncro KT-531P

■Length 1400mm
■Width 1600mm
■Weight EP/2,550g (approx.), GP/2,450g (approx.)
■Motor 600-1000W BL Motor (sold separately)
■Engine 2 Cycle 40-46 class engine (sold separately)
■Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area 44dm2
■Wing Loading 55.7-55.9g/dm2
■Airfoil Original semi-symmetrical
■Propeller size D11 x P7-D12 x P8 (sold separately)
■Tire size Nose 60mm / Main 60mm
■Dihedral 2.5°
■Side Thrust 2°
■R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP) 4ch, 5 servo (sold separately)

■Length 1400mm
■Width 1600mm
■Weight EP/2,550g (approx.), GP/2,450g (approx.)
■Motor 600-1000W BL Motor (sold separately)
■Engine 2 Cycle 40-46 class engine (sold separately)
■Battery (EP) 14.8V-4,000-5,000mAh Li-Po battery (sold separately)
■Main Wing Area 44dm2
■Wing Loading 55.7-55.9g/dm2
■Airfoil Original semi-symmetrical
■Propeller size D11 x P7-D12 x P8 (sold separately)
■Tire size Nose 60mm / Main 60mm
■Dihedral 2.5°
■Side Thrust 2°
■R/C system (EP) 4ch, 4 servo, 1 ESC (sold separately)
■R/C system (GP) 4ch, 5 servo (sold separately)

■Length 463mm
■Width 220mm
■Height 129mm
■Wheelbase　258mm
■Tread (F/R)　176mm
■Tire(F/R)　φ66×25mm
■Gear Ratio　7.47 / 5.44:1
■Weight　1,800g (approx.)
■Engine KE15SP with recoil starter

■Length 174.0mm
■Width 75.0mm
■Height 45.5mm
■Wheelbase 98.0mm （LL）
■Tread Wide
■Chassis RWD（MR-03）
■Motor Mount MM
■Front Wheel Offset Narrow +1.5mm
■Front Wheel Offset Wide +1.5mm
■R/C System Syncro KT-531P

<Readyset Contents>
●Fully assembled and painted chassis
●3ch transmitter

<Required for Operation>
●1 x PP3 9V alkaline battery for transmitter
●4 x AAA alkaline batteries for model

<Readyset Contents>
●Fully assembled and painted chassis
●3ch transmitter

<Required for Operation>
●1 x PP3 9V alkaline battery for transmitter
●4 x AAA alkaline batteries for model

Domestic limited number: 150

■Length 490mm
■Width 307mm
■Height 180mm
■Wheelbase 325mm (Can be changd by replacing rear hub collars）
■Tread(F/R) 254mm
■Tires(F/R) (sold separately)
■Gear Ratio 10.87 : 1　Pinion 14T
■Weight 3,650g (approx.)
■R/C system 2～3ch (sold separately)

■Length 178.0mm
■Width 80.0mm
■Height 45.0mm
■Wheelbase 102.0mm（3L）
■Tread F : 68.5mm R : 65.0mm
■Chassis RWD（MR-03）
■Motor Mount LM
■Front Wheel Offset Narrow +3.5mm
■Front Wheel Offset Wide +1.0mm
■R/C System Syncro KT-531P

■Length 464mm
■Width（Body width） 200mm（207mm）
■Height　126mm
■Wheelbase 260mm
■Tread (F/R) F：174mm／R：174mm
■Tires (F/R) F：φ66×25mm／R：φ66×25mm
■Gear Ratio 6.5：1
■Weight 1650g(approx.)
■Syncro KT-231P+ transmitter
■Motor G14L

■Length 177mm
■Width 78mm
■Height 47.5mm
■Wheelbase 98mm （LL）
■Chassis RWD (MR-03)
■Motor Mount MM
■Front Wheel Offset Narrow +3.0mm (for RWD)
■Rear Wheel Offset Wide +3.0mm (for RWD)
■R/C System Syncro KT-531P

■Length 193mm
■Width 84mm
■Height 90.0mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 242g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：1
■Front Tire Diameter Φ37.0mm
■Rear Tire Diameter Φ37.0mm
■Front Tire Width 12mm
■Rear Tire Width 12mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins

■Length 193mm
■Width 84mm
■Height 90.0mm
■Chassis Type MX-01
■Wheel Base 120mm
■Tread F/R:72.7mm
■Weight 242g (excl. battery)
■Motor/Engine 130 Class
■Gear Ratio 55.44：1/46.20：1/39.60：1
                    34.65：1/30.80：1/27.72：
■Front Tire Diameter Φ37.0mm
■Rear Tire Diameter Φ37.0mm
■Front Tire Width 12mm
■Rear Tire Width 12mm
■Battery 4 x AAA Alkaline
■Transmitter Syncro KT-531P
■Speed：Approx. 2.7km/h〜5.4km/h  (Pinion gears 10T〜 20T)
■Running Time Approx. 60 mins
