Optional parts for the 1/8 Inferno MP10 Buggy series. The standard knuckle has a kingpin angle of 0°, while this set features knuckles with 7°kingpin angle. This design reduces front tire catching, particularly in high-speed corners, allowing for higher cornering speeds. It also improves stability, enabling the vehicle to better absorb sudden movements caused by surface gaps or irregularities.

■Length (Body included) 462mm
■Width (Body width * Excluding mirrors) 195mm
■Width (chassis) 212mm
■Height 134mm
■Chassis Height 12mm (approx.)
■Wheelbase 260mm (240-273mm ※Adjustable)
■Tread（F）172mm
■Tread（R）170mm
■Gear Ratio 9.1：1
■Tread（F/R）φ63×24mm
■Weight 約1,450g
■Motor G22
■R/C system  Syncro KT-231P+

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●1.5/2.0mm Hexagonal wrench
●Cross wrench (small)
●Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

For the MR-04 EVO2 chassis. Friction shock for the MR-04MM, featuring carbon plates. It contributes to improved vehicle stability at high speeds. The set includes three springs of varying stiffness levels. The friction shock is compatible with the standard pitching shock and the MZW432B rear oil shock. It can also be used with the MZW708 aluminum oil shock mount.

■Length 178.0mm
■Width 78.0mm
■Height 40.0mm
■Chassis MR-04W-LM
■Wheelbase 102.0mm （3L）
■Tread  F:66.5mm R:65.0mm
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide  +1.0mm
■Weight 130g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 168.0mm
■Width 72.0mm
■Height 48.0mm
■Chassis MR-04N-RM
■Wheelbase 90.0mm （M）
■Tread F:59.5mm R:59.0mm
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Wide ±0.0mm
■Weight 169g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 168.0mm
■Width 72.0mm
■Height 48.0mm
■Chassis MR-04N-RM
■Wheelbase 90.0mm （M）
■Tread F:59.5mm R:59.0mm
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Wide ±0.0mm
■Weight 169g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 507mm
■Width 307mm
■Height 189mm
■Wheelbase 325.5mm
■Tread (F/R) 258mm／261mm
■Tire (F/R) φ116×44mm／φ116×44mm
■Gear Ratio 11.70：1
■Weight 3,400g (approx.)
■Engine KE21SP
■Transmitter 2.4GHz Syncro KT-231P+

＜Readyset Contents＞
●Factory assembled chassis complete with control linkages
●Finished body complete with printed color scheme
●2.4GHz Syncro KT-231P+ transmitter
●Break in ring
●1.5、2.0、2.5、3.0mm L shaped hex wrenches
●Cross wrench
●17mm wheel wrench

<Required for Operation>
●Glow fuel
●8 x AA size alkaline batteries for transmitter and receiver
●Engine starting tools (fuel bottle, plug heater)
●Tool

■Length 507mm
■Width 307mm
■Height 189mm
■Wheelbase 325.5mm
■Tread (F/R) 258mm／261mm
■Tire (F/R) φ116×44mm／φ116×44mm
■Gear Ratio 11.70：1
■Weight 3,400g (approx.)
■Engine KE21SP
■Transmitter 2.4GHz Syncro KT-231P+

＜Readyset Contents＞
●Factory assembled chassis complete with control linkages
●Finished body complete with printed color scheme
●2.4GHz Syncro KT-231P+ transmitter
●Break in ring
●1.5、2.0、2.5、3.0mm L shaped hex wrenches
●Cross wrench
●17mm wheel wrench

<Required for Operation>
●Glow fuel
●8 x AA size alkaline batteries for transmitter and receiver
●Engine starting tools (fuel bottle, plug heater)
●Tool

■Length 160.0mm
■Width 72.0mm
■Height 51.0mm
■Wheelbase 94.0mm（L）
■Tread  F : 59.5mm R : 59.5mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +1.5ｍｍ
■Rear Wheel Offset Narrow +1.5ｍｍ
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Syncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal tool

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter

■Length (Body included) 441mm
■Width (Body width * Excluding mirrors) 208mm
■Width (chassis) 208mm
■Height 136mm
■Chassis Height 12mm (approx.)
■Wheelbase 260mm (240-273mm ※Adjustable)
■Tread（F）172mm
■Tread（R）180mm
■Gear Ratio 9.1：1
■Tread（F/R）φ63×24mm
■Weight 約1,450g
■Motor G22
■R/C system  Syncro KT-231P+

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●1.5/2.0mm Hexagonal wrench
●Cross wrench (small)
●Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tools

■Length 181.0mm
■Width 78.0mm
■Height 40.0mm
■Chassis MR-04W-LM
■Wheelbase 102.0mm （3L）
■Tread  F:68.5mm R:66.0mm
■Front Wheel Offset Narrow +2.7mm
■Rear Wheel Offset Wide  +0.8mm
■Weight 130g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

●Scale: Approximately 1/28 scale
●Product size：L160 x H50.5 x D73.9（mm）
●Product weight：109g (approx.)
●Package size：W215 × H225 × D115（mm）
●Package weight：Approximately 343g
●Maximum speed: Training mode: 7km/h Racing mode: 10km/h
●Operation distance: approx. 30m
●Frequency: 2.4GHz (12 vehicles can run simultaneously)
●Continuous running time: Approximately 60 minutes (when using new alkaline batteries)
●Target age: 6 years old or older

<Kit Content>
●Main unit
●2.4GHz controller with stopwatch
●Mini pylons (6 pieces)
●Trim adjuster
●Battery holder
●Seal

<Required to run>
●AA-size alkaline batteries x 2 for chassis (Not included)
●AA-size alkaline batteries x 2 for transmitter (Not included)

●Scale: Approximately 1/28 scale
●Product size：L183 x H76x D82（mm）
●Product weight：144g (approx.)
●Package size：W215 × H225 × D115（mm）
●Package weight：407g (approx.)
●Maximum speed: Training mode: 7km/h Racing mode: 10km/h
●Operation distance: approx. 30m
●Frequency: 2.4GHz (12 vehicles can run simultaneously)
●Continuous running time: Approximately 60 minutes (when using new alkaline batteries)
●Target age: 6 years old or older

<Required to run>
●AAA-size alkaline batteries x 2 for chassis (sold separately)
●AAA-size alkaline batteries x 2 for transmitter (sold separately)

■Length　490mm
■Width　307mm
■Height　180mm
■Ground clearance　28mm
■Wheelbase　325mm
■Tread（F / R）　254mm
■Tires（F / R）　sold separately
■Gear Ratio　12.19：1
■Weight　3390g(approx.)
■Engine　21Class (sold separately)

＜Kit Contents＞
●Unassembled chassis kit
●Wing
●Special clear body
●Window mask seal
●Logo decals
●Fuel tube
●Linkage parts
●Clutch parts
●Air cleaner
●Ring gear grease
●1.5, 2.0, 2.5mm Hexagonal wrench
●Cross wrench
●Wheel wrench

＜Required for Operation＞
●2-channel 2-servo R/C system for cars
●Compatible batteries for R/C system
●21 engine
●Wheels & Tires w/foam inserts for 1/8 buggy
●Starter box
●Plug heater
●Muffler & manifold
●Fuel
●Fuel bottle
●Oil for air cleaner
●Shock oil
●Diff oil
●Paint for car body
●Instant adhesive
●Tools
●Screw lock material

■Length 177.0mm
■Width 76.5mm
■Height 45.0mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:64.5mm R:64.0mm
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Wide +2.5mm
■Weight 165g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 166.0mm
■Width 78.0mm
■Height 44.0mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:66.5mm R:65.0mm
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide +3.0mm
■Weight 170.4g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 173.0mm
■Width 78.0mm
■Height 45.0mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:67.5mm R:65.0mm
■Front Wheel Offset Narrow +3.0mm
■Rear Wheel Offset Wide +3.0mm
■Weight 171g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 173.0mm
■Width 78.0mm
■Height 45.0mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:67.5mm R:65.0mm
■Front Wheel Offset Narrow +3.0mm
■Rear Wheel Offset Wide +3.0mm
■Weight 171g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 173.0mm
■Width 78.3mm
■Height 45.64mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:66.5mm R:64.0mm
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide +2.5mm
■Weight 169g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 173.0mm
■Width 78.3mm
■Height 45.64mm
■Chassis MR-04W-MM
■Wheelbase 98.0mm （LL）
■Tread F:66.5mm R:64.0mm
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide +2.5mm
■Weight 169g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

• •

    Instruction Manual

※The user manual is not included with this product. You can download the user manual from the following link.

<Kit Content<
●MR-04 EVO2-W-MM Factory assembled chassis with KYOSHO SPEED HOUSE KV5600 brushless motor
●Parts set for changing front tread
●6T・7T・8T・9T Pinion gears
●Wheel wrench
●Tools for pinion gears
●Spare wheel nuts

＜Required for Operation＞
●Transmitter
●Receiver unit (Compatible with EVO/EVO2)
●ASC
●AAA x 4 batteries for chassis
●Batteries for transmitter

• •

    Instruction Manual

※The user manual is not included with this product. You can download the user manual from the following link.

<Kit Content>
●MR-04 EVO2-W-MM Factory assembled chassis with KYOSHO SPEED HOUSE KV8500 brushless motor
●Parts set for changing front tread
●6T・7T・8T・9T Pinion gears
●Wheel wrench
●Tools for pinion gears
●Spare wheel nuts

＜Required for Operation＞
●Transmitter
●Receiver unit (Compatible with EVO/EVO2)
●ASC
●AAA x 4 batteries for chassis
●Batteries for transmitter

■Length (Body included) 452mm
■Width (Body width * Excluding mirrors) 192mm
■Width (chassis) 190mm
■Height 135mm
■Chassis Height 12mm (approx.)
■Wheelbase 274mm (240-274mm ※Adjustable)
■Tread（F）172mm
■Tread（R）180mm
■Gear Ratio 9.1：1
■Tread（F/R）φ63×24mm
■Weight 約1,450g
■Motor G22
■R/C system  Syncro KT-231P+

<Kit Contents>
●Completed chassis with R/C radio installed
●Factory assembled body complete with color scheme
●Syncro KT-231P+ transmitter
●1.5/2.0mm Hexagonal wrench
●Cross wrench (small)
●Setting change parts

<Required for Operation>
●4 x AA batteries for transmitter
●Battery for chassis (recommended: 7.2V Ni-MH battery)
●Charger for battery for chassis
●Tool

■Length 180.0mm
■Width 78.0mm
■Height 40.0mm
■Chassis MR-04W-LM
■Wheelbase 102.0mm （3L）
■Tread F:64.5mm R:63.0mm
■Front Wheel Offset Narrow +1.5mm
■Rear Wheel Offset Wide  ±0.0mm
■Weight 182.2g
■R/C System Syncro KT-531P

<Readyset Contents>
●Factory assembled chassis
●Pre-painted body, complete with markings
●2.4GHz Perfex KT-531P 2.4GHz transmitter
●Front tread adjustment parts set
●Pinion gears 6T, 7T, 8T, 9T
●Spare nuts
●Wheel wrench
●Pinion gear tool
●Tires, wheels

<Required for Operation>
●AAA-size alkaline batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for transmitter

■Length 161.0mm
■Width 72.0mm
■Height 52.0mm
■Wheelbase 94.0mm（L）
■Tread F : 61.5mm R : 59.0mm
■Chassis MA-020-N
■Front Wheel Offset Narrow +2.5mm
■Rear Wheel Offset Wide ±0.0mm
■Weight 193g
■R/C System Syncro KT-531P

<Ready set contents>
● R / C unit built-in complete chassis
● Painted and marked complete body
● Ｓyncro KT-531P transmitter
● Mini pylon
● Pinion gear (15T, 17T, 19T, 21T)
● Spur gear (27T, 29T, 31T)
● Spare nut
● Wheel wrench
● Pinion removal too

＜ Required for Operation ＞
●AAA-size alkaline batteries x 4 or Ni-MH batteries x 4 for chassis.
●AAA-size alkaline batteries x 4 for transmitter
